$14,353.00
The T25 tractor is proof that great things can indeed come in small packages. Offering enhanced power without sacrificing maneuverability, it’s equipped with a powerful engine and ergonomic operator controls, ensuring both performance and comfort.
T25H Specs
| Engine | |
| Engine manufacturer | Yanmar 3TNV80F |
| Type | Natural aspiration |
| Engine power | 24.7 hp | 18.4 kW |
| PTO power | 18.3 hp | 13.6 kW |
| Rated engine speed | 3000 rpm |
| No. of cylinders | 3 |
| Displacement | 77.3 cu. in. | 1267 cc |
| Air cleaner | Single dry |
| Alternator | 12V, 40A |
| Fuel system | IDI |
| Hydraulic System | |
| Pump type | Single gear pump |
| Implement flow | 4.2 gpm | 15.8 L/min |
| Steering flow | 2.8 gpm | 10.5 L/min |
| Total flow | 6.9 gpm | 26.3 L/min |
| Category, 3-point hitch | I |
| Hitch lift capacity | 1551.2 lb | 703.6 kg |
| Hitch lift capacity at 24 inches behind link ends | 1229.7 lb | 557.8 kg |
| Lift control type | Position |
| No. of standard remote valves | 1 |
| Powertrain | |
| Transmission type | HST |
| No. of speeds | Infinite 2-Range |
| Max. traveling speed | 13.7 mph | 22 km/h |
| Brakes | Wet disc |
| Steering | Hydrostatic |
| Clutch | N/A |
| PTO | |
| PTO type | Independent |
| PTO control | Electric/Hydro |
| PTO rear | 540 rpm |
| Capacities | |
| Fuel tank | 6.6 gal | 25 L |
| Coolant | 3.8 qt | 3.6 L |
| Crankcase | 2.9 qt | 2.7 L |
| Transmission/Hydraulics system | 4.5 gal | 17 L |
| Front axle | 4.7 qt | 4.5 L |
| Dimensions & Weights | |
| Overall length with 3-point hitch | 102.8 in. | 2610 mm |
| Overall width | 50 in. | 1270 mm |
| Wheelbase | 61 in. | 1550 mm |
| Height to top of ROPS | 91.3 in. | 2320 mm |
| Height to top of cabin | – |
| Min. ground clearance | 10.2 in. | 260 mm |
| Min. turn radius with brakes | 94.1 in. | 2390 mm |
| Min. turn radius without brakes | 111.8 in. | 2840 mm |
| Weight with ROPS | 2046 lb | 928 kg |
| Weight with cab | – |
| Standard Tires | |
| R1 Agricultural – Front | 6-12 4PR |
| R1 Agricultural – Rear | 9.5-20 6PR |
| R3 Turf – Front | Turf Master 23×8.50-12 NHS TL 4PR |
| R3 Turf – Rear | Multi-Trac CS 33×12.50-16.5 NHS TL 4PR |
| R4 Industrial – Front | Trac Chief 23×8.50-14 NHS TL 4PR |
| R4 Industrial – Rear | 36X12.5-15 |
