| Motor |
| Model |
Cummins B6.7 |
| type |
Water-cooled, inline six-cylinder, turbocharged, common-rail high-pressure |
| Number of cylinders |
6 |
| Emissions standard |
Tier 4 / Euro V |
| displacement |
6.7 l |
| Rated power |
129 kW / 2200 rpm |
| hydraulic system |
| type |
Axial piston pump with variable flow rate |
| Flow rate |
2×250 + 20 l/min |
| Digging forces (ISO6015) |
| Bucket digging force |
137 kN / 148 kN |
| Arm digging strength |
99 kN / 107 kN |
| Spoon |
| type |
Baking spoon |
| capacity |
0.45–1.2 (1.1) m³ (SAE) |
| Width |
1309 mm |
| Drive |
| traction motor |
GM41 |
| rollers |
2×9 |
| Support rollers |
2×2 |
| chain links |
2×49 |
| Driving speed |
3.3 / 5.3 km/h |
| traction |
214 kN |
| climbing ability |
70% (35°) |
| Swivel system |
| Swivel motor |
HM5X130 |
| Panning speed |
0–11 rpm |
| Filling quantities |
| fuel tank |
405 l |
| Cooling system |
33 liters |
| engine oil |
25 liters |
| Hydraulic oil tank |
190 l |
| Complete hydraulic system |
300 liters |
| Operating weight & ground pressure |
| Operating weight |
23,800 kg |
| Ground pressure |
49.3 kPa |
| Working range (mm) (Boom: 5700 mm / Arm: 2925 mm) |
| A – Max. digging height |
10,060 |
| B – Max. discharge height |
7170 |
| C – Max. digging depth |
6510 |
| D – Vertical digging depth |
5800 |
| E – Digging depth at 2500 mm level ground |
6300 |
| F – Max. Range |
9865 |
| G – Range at ground level |
9670 |
| H – Min. swivel radius (work equipment) |
2970 |
| Dimensions (mm) |
| A – Total length |
9630 |
| B – Ground support (transport) |
5020 |
| C – Height (up to boom) |
3060 |
| D – Total width |
2980 |
| E – Height (up to cabin) |
3100 |
| F – Counterweight ground clearance |
1070 |
| G – Min. ground clearance |
470 |
| H – Tail swing radius |
2980 |
| I – track gauge |
3655 |
| J – Chain length |
4456 |
| K – Chain track width |
2380 |
| L – Chain width |
2980 |
| M – shoe width |
600 |
| O – Bonnet height |
2575 |
| P – frame width |
2725 |
| Q – Distance swivel center to tail |
2910 |
