$11,497.00
| Model | Kubota D902 |
|---|---|
| type | Three-cylinder direct injection |
| Number of cylinders | 3 |
| Emissions standard | Tier 4 / Euro 5 |
| displacement | 0.989 l |
| Rated power | 11.8 kW @ 2,300 rpm |
| type | Piston variable displacement pump |
|---|---|
| Operating flow | 64.4 l/min |
| Swivel motor | NACHI |
| Panning speed | 0–10 rpm |
| brake | Mechanical brake |
| Digging forces (ISO6015) | Bucket 16 kN · Arm 9.5 kN |
|---|---|
| Drive | piston engine |
| rollers | 3×2 |
| Driving speed | 2.4 / 4.2 km/h |
| traction | 18 kN |
| Max. digging height | 3,535 mm |
|---|---|
| Max. discharge height | 2,445 mm |
| Max. digging depth | 2,270 mm |
| Vertical digging depth | 1,910 mm |
| Max. range | 3,925 mm |
| Range at ground level | 3,860 mm |
| Total length | 3,845 mm |
|---|---|
| Floor support (transport) | 2,460 mm |
| Height (up to boom) | 1,105 mm |
| Total width | 990 / 1,300 mm |
| Height (up to cabin) | 2,400 mm |
| Counterweight ground clearance | 460 mm |
| Min. ground clearance | 145 mm |
| Tail swing radius | 1,070 mm |
| track gauge | 760 / 1,070 mm |
| Chain length | 1,230 mm |
| Chain track width | 1,593 mm |
| Chain width | 230 mm |
| Frame width | 990 mm |
| Distance swivel center → rear | 1,070 mm |
| Operating weight | 2,000 kg |
| Ground pressure | 30 kPa |
Source: bagger2go.de – Values may vary slightly depending on equipment.
