$9,497.00
| Model | Kubota D902 |
|---|---|
| type | Water-cooled 3-cylinder engine |
| Emissions standard | Euro 5 / Stage V |
| displacement | 0.898 l |
| Performance | 16 hp (11.8 kW) / 2,300 rpm |
| pump | Axial piston variable displacement pump Hengli HP5VS28 |
|---|---|
| control block | Hengli HVSE-09 |
| Traction motors | Eddie FTM01 |
| Swivel motor | Eaton SW2.5K |
| Max. hydraulic flow | 64.4 l/min |
| AUX 1 | 28 l/min |
| AUX 2 | 15 l/min |
| Operating weight | 1,800 kg |
|---|---|
| Transport width | 990–1,300 mm (adjustable chassis) |
| Transport length | 3,585 mm |
| Transport height | 2,360 mm |
| Digging depth | 2,270 mm |
| Vertical digging depth | 1,910 mm |
| Max. range on the ground | 3,845 mm |
| Max. discharge height | 2,445 mm |
| Chassis length | 1,670 mm |
| Ground clearance | 230 mm |
| Transport length | 3,575 mm |
|---|---|
| Total height | 2,405 mm |
| Transport width (retracted) | 990 mm |
| Transport width (extended) | 1,300 mm |
| Drive length | 1,587 mm |
| Tail swing radius | 650 mm |
| Ground clearance (counterweight) | 450 mm |
| Chain width | 230 mm |
| Shield lifting height / immersion depth | 280 mm / 190 mm |
Values may vary slightly depending on equipment. Information provided without guarantee.
