| Motor | |
| Model | Cummins QSF3.8T |
| type | EFI, water-cooled, turbocharged |
| Number of cylinders | 4 |
| Emissions standard | Tier 4 / Euro V |
| displacement | 3.8 l |
| Rated power | 90 kW / 2200 rpm |
| hydraulic system | |
| type | 2 piston pumps + 1 fixed pump |
| Operating flow | 2×130 l/min |
| Digging forces (ISO6015) | |
| Bucket digging force | 97 kN |
| Arm digging strength | 70 kN |
| Spoon | |
| type | Baking spoon |
| capacity | 0.3–0.65 (0.6) m³ |
| Width | 1039 mm |
| Drive | |
| type | axial piston motor |
| rollers | 7×2 |
| Support rollers | 1×2 |
| chain links | 44×2 |
| Driving speed | 3.2 / 5.4 km/h |
| traction | 118 kN |
| climbing ability | 70% (35°) |
| Swivel system | |
| Swivel motor | Swashplate piston engine |
| Panning speed | 0–10.9 rpm |
| brake | Mechanical brake |
| Filling quantities | |
| fuel tank | 265 liters |
| Cooling system | 20 liters |
| engine oil | 12 liters |
| Hydraulic oil tank | 177 liters |
| Complete hydraulic system | 183 liters |
| Operating weight & ground pressure | |
| Operating weight | 14,620 kg |
| Ground pressure | 43.8 kPa |
| Dimensions (mm) (Boom: 4600 mm / Arm: 2500 mm) | |
| A – Total length | 7920 |
| B – Ground support (transport) | 4390 |
| C – Height (up to boom) | 2860 |
| D – Total width | 2645 |
| E – Height (up to cabin) | 3263 |
| F – Counterweight ground clearance | 915 |
| G – Min. ground clearance | 425 |
| H – Tail swing radius | 2380 |
| I – track gauge | 2700 |
| J – Chain length | 3645 |
| K – Chain track width | 2000 |
| L – Chain width | 2500 |
| M – shoe width | 500 |
| O – frame width | 2490 |
| Q – Distance swivel center to tail | 2375 |
| Working area (mm) | |
| A – Max. digging height | 8495 |
| B – Max. discharge height | 6060 |
| C – Max. digging depth | 5490 |
| D – Vertical digging depth | 4625 |
| E – Max. Range | 7820 |
| F – Range at ground level | 8300 |
| G – Min. swivel radius (work equipment) | 2445 |
